Double Die-Cut Machine

Advanced dual-station system for simultaneous cutting and perforating.

Double Die-Cut Machine, view 1 of 3

* Images and technical schematics are for illustrative purposes. Final machine configuration is tailored to client specifications.

The double die-cut machine is the most perfect machine to have in your production. This will be able to die-cut and in registration perforating. The 2 die-station can be manually adjusted to let the perforation cut in registration with the 1st die-station. The Die stations have both separate Servo motors to meet these demands.

Technical Specifications

Compressed Air
6 Bar (Dry) 1000 M3
Electric
400VAC 32 AMP
Mechanical Speed
Up to 200m/min
Knife Station
5 crush cut knives (Optional: Shearer/Auto)
Webguide
BST
Unwinder
1 meter
Rollift Diameter
76 mm
Die-Station
2x Kocher and Beck
Format
Z-96 to Z-168
Rewind
Single shaft 76mm (Optional Double / Semi Turret)
